          Fraunhofer Evaluates Density Determination Methods of Additively
          Manufactured Parts
                                             urement  methods for density deter-  nation works
                                             mination in additive  manufacturing”   Philipp Pruesse of Dimensionics Den-
                                             — the use of micrographs, computed   sity described how the automated
                                             tomography, and the  manual Archi-  density determination process works.
                                             medes method were evaluated in ad-  “Our  process uses  the  Archimedes
                                             dition to automated density determi-  method  mentioned  above,  but  in
                                             nation.                             combination with modern automa-
                                             All of the methods are essentially ca-  tion  technology.  The  samples  to  be
                                             pable of determining the relative den-  measured are placed in a special com-
                                             sity of AM parts, but the Fraunhofer  ponent carrier, which is provided with
                                             IAPT report found that there are sub-  openings on the underside. These

          Report notes that automated density   stantial differences in accuracy, reso-  component carriers are transported
          determination  developed  by  Dimen-  lution, repeatability, and the possibility  through the system by an axis robot
          sionics Density excels in repeatability   of defect detection.         and, thus, lowered centrally and pre-
          and traceability.                  Micrographs  destroy  the  AM  speci-  cisely onto the scales. On the scales
                                                                                 themselves,  a lift-out rack with pins
             study comparing various density   men.  While they  can provide partial   is placed, which lifts the component
          A measurement  methods of parts    insight  into the  actual condition of   over the openings in the component
          produced by additive  manufacturing   pores in a part, the process is charac-  carrier, lifting it out of the carrier. The
          (AM) commissioned by  Germany’s    terized by a lot of manual work, add-  automated handling eliminates human
          Fraunhofer IAPT has found that  au-  ing time and cost and relying on a high   influence on the measurement, as the
          tomated density determination de-  degree  of expertise,  writes  Dimen-  parts are always placed identically
          veloped by Dimensionics Density has   sionics Density in the press release.  onto the  scales.  The  scales  are  de-
          advantages in certain areas.       Computed tomography (CT) also re-   signed to be insulated from vibration.
          Density determination of AM parts   quires expertise. While it can provide   In addition,  all  ambient  conditions
          can be critical because of its impact   a realistic 3D image of the internal po-  such as temperature, air pressure, and
          on their structural integrity and per-  rosity of a part, it is restricted in the   water temperature, are recorded via
          formance, according to Dimensionics   pore size that it can detect. Moreover,   climate  sensors,  and  their  influence
          Density. It enables manufacturers to   CT  equipment can be prohibitively   on the  measurement  result  is  taken
          ensure part quality and reliability and   expensive.                   into account directly in the evaluation
          helps identify defects,  porosity, and   The Archimedes method is the easiest   algorithm when determining the den-
          voids within the material. Compared   to use but can be the least accurate,   sity,” said Pruesse.
          with three  other  density  determina-  as the results can be affected by envi-  The only traceable method
          tion techniques, the method devel-  ronmental conditions, the accuracy of
          oped by Dimensionics Density is par-  the balance, as well as the precision of   The  Fraunhofer  IAPT  benchmarking
          ticularly recommended when density   the experimental procedure. It is dif-  report notes that Dimensionics Den-
          evaluation has to be made quickly or   ficult to reproduce the results, which   sity’s  automated  density  determina-
          frequently, according to the Fraun-  are strongly influenced by human fac-  tion removes the user from the Archi-
          hofer report. It also allows simplifica-  tors, according to Dimensionics Den-  medean measurement and, therefore,
          tion of machine approvals, potentially   sity. Test specimens are never placed   has  significantly  higher  repeatability
          reducing quality assurance costs.  exactly the same on the balance, and   and  fewer  fluctuations.  The  report
                                                                                 also states that this method is the only
          Comparison of four density deter-  the manual operation of the balances   one that is traceable, such that it can
          mination methods                   leads to measurement deviations.    be referenced to a recognized stand-
          In the  report  — “Analysis of meas-  How automated density determi-   ard via a measurement chain.
