          But this is not a commercial line ready for prime time   body. If any process is defective, electronic sensors notify
          production. We hope to find a strategic partner with whom   the operator and that unit is automatically ejected.
          we can bring our technology to the next level.” The layout   The assembled container exits the assembly module and
          of the prototype line is shown in a line drawing included   enters a flow wrapper and shrink tunnel. Just ahead of
          in this story. The UHT pasteurizing equipment shown at   the  flow  wrapper,  a  Markoprint  X1JET  digital  thermal
          the beginning is not something provided by 3EPack and   ink-jet printer from Weber Marking Systems puts date and
          is included primarily for purposes of illustration. “Many   lot code on each body. As containers exit the shrink tunnel,
          customers already have a pasteurizer, and keep in mind   a wrapped straw is automatically applied to the shrink
          that those who use the package for water won’t need a   wrap. “For more than two years we’ve been looking for
          pasteurizer at all,” says Saslekov.
                                                                a company able to produce the U-shaped biodegradable
          A quick look at the equipment in action is available.   straws from PLA,” says Saslekov. “Finally we found Matrix
          Film is unwound into an aseptic vf/f/s system, which   Pack, a producer in Greece. We’re also looking for a source
          incorporates a “patent-pending film sterilization process.”   that can thermoform our lid from PLA. Again, we have
          Essentially it’s an application of a 3% hydrogen peroxide   found some who can make it. But the minimum order is
          solution plus exposure to UVC light. Commonly used to   currently a barrier.”
          decontaminate surgical instruments, UVC light has a   In some ways the genius of a concept like this is that
          wavelength of between 200 to 400 nanometers and is    multiple  bets  are  covered  where  sustainability  is
          effective at killing bacteria by destroying the molecular   concerned. If consumers behave responsibly, 100% of the
          bonds that hold their DNA together. Filled pouches move   materials in the container will be recycled. Enormously
          then to an assembly module that relies to a great extent   helpful on the recycling front is that the effort required
          on an oval-shaped track around which stainless steel molds   to get the materials into the correct recycle stream is
          continuously travel. These molds stop at various stations   minimized because of the uniquely and deliberately flimsy
          so that a number of automated processes can take place.
                                                                nature of the package structure. If consumers behave
          First, vacuum cups pick a flat paperboard body from a   less than responsibly  and  fail to  put  these  packaging
          magazine feed, erect it, and pull it into a mold. The mold   components into the appropriate recycle streams, 75%
          closes and moves along its oval-shaped track to a station   of the materials involved are compostable under natural
          where the two arms of a pick-and-place device alternate   conditions. Translation: 75% of the materials will NOT wind
          in picking an octagonal-shaped corrugated base and    up floating in the Pacific garbage patch.
          placing it into a body. The bases are delivered by way of a    When we challenged Saslekov on just how recyclable is
          rotary-style hopper that separates, sorts, and feeds them   the seven-layer coextrusion used for the inner pouch, he
          into two parallel discharge lanes leading to the station   said this: “Maybe in the U.S. such a plastic would not be
          where they get picked and inserted into the body. The   recycled, but in many countries around the world it would
          corrugated  base  is  supported  by  the  bottom  flaps  of    be.” Even if he is wrong on that point, he emphasizes
          the body.
                                                                that today only about 20% of all reclyable containers are
          Now the mold moves to the next station: pouch insertion.   in fact recycled. So that makes the 3EPak bottle, which
          The  beverage-filled  pouches  are  conveyed  up  a  short   only contains 5 g of plastic, considerably less harmful to
          incline conveyor and drop into a chute that delivers each   the environment than a typical 22.5-g PET bottle for a
          pouch into a mold. In the next station, mechanical fingers   shelf-stable juice product. “If this package replaces only
          smooth the pouch’s top corners out over the body’s edges.   2% of the plastic bottles sold globally today, plastic usage
          In the next station, the thermoformed lids—which, much   will be reduced by about 114,640,000 pounds per year,”
          like the corrugated bases, are separated, sorted, and   says Saslekov.  So where does 3Epak stand currently? “The
          delivered to the assembly module in two parallel lanes by a   most important goal is to find strategic partners,” says
          rotary-style hopper—are applied by the two arms of a pick-  Saslekov. “Considering that this format offers the best
          and-place device that also resembles the one responsible   combination  of  cost, extended shelf life, recyclability,
          for applying corrugated bases. The lids are pressed down   and biodegradability, we think such partners will step
          to firmly pinch the pouch’s corners against the paperboard   forward soon.”
