FeAtures




          output. With industrial robots, when guarding is a concern,   Three-plate & stack molds
          many times we simply utilize a conveyor package with   To run these popular applications efficiently, robots must
          integrated guarding. The guarding would be attached to
          the conveyor, and the entire system could quickly and   be equipped with two arms to extract the parts and
                                                                runners between each set of plates. A single-arm six-axis
          easily be rolled away from the press, to use on another
          work cell, or simply move away during mold changes.   robot would not be ideal for these applications, as it would
                                                                dramatically impact the cycle time.
          Control cabinets
                                                                Support
          Because Cartesian robot manufacturers understand that
          floor space is at such a premium in a molding shop, they   Of  course,  articulated-arm  robot manufacturers  have
                                                                technical support.  The main difference is that their
          have almost exclusively moved to mounting the control
          cabinets on the robot traverse beam. Six-axis robots   personnel may not necessarily know the injection molding
                                                                process and equipment. When calling support, it certainly
          require a separate control cabinet that will require
          additional floor space.                               must be helpful when supplier personnel understands
                                                                common terms related to robot sequencing in molding
          Features specific to the injection molding            applications—like core pull, screw recovery, air blast,
          process                                               cooling time and ejector sequencing.Many issues that arise

          Gantry robot manufacturers have been working constantly   are related to the molding machine and robot interface.
          to  help  make  the  molding  process  more  efficient.  We   Again, gantry robot manufacturers understand how that
          now have features such as Soft Torque, which allows the   interface functions. This allows them to quickly ascertain
          ejectors to push the arm back with assistance from the   what the problem may be and whether it is robot- or
          robot. The robot monitors the force applied during this   machine-related.
          motion and applies a counterforce to move the arm back.  Robot/ press integration

          Find & Pick is a feature for use with robots on older   Some Cartesian robot manufacturers allow their robots
          hydraulic  presses  that  may have  a  tendency  for  their   to be integrated with the molding machines.  This
          clamp position to vary from shot to shot. With this feature,   integration allows the robot programs to be accessed
          the robot will vary the part-removal position based on   and saved directly through the injection press controller.
          fluctuations in the clamp position. Six-axis robots don’t   Also, remote diagnostics of both the machine and robot
          necessarily have features like these that are specific to   can easily be accomplished to determine where an issue
          the injection molding process.                        may lie.
          Robot layout configurations                           In conclusion, six-axis and collaborative robots definitely

          Cartesian robot manufacturers offer a variety of      have a place in the plastics industry, but are not ideally
          mounting options to accommodate project needs and     suited to the removal of parts from molding machines.
          space constraints. Although traditional “operator side”   In almost 25 years of working with automation in the
          and “rear side” configurations are still popular, we are   plastics industry, I have seen only a small number of
          seeing  more  and  more  varied  layouts.  Configurations   companies utilize six-axis robots to remove parts from
          such as “T-Mount,” “Clamp End” and “Reverse Mount”    molding machines.  Many of those same companies later
          are becoming more popular. Floor space becomes an     switched back to Cartesian-style takeout robots. More
          increasingly hot commodity as more and more companies   often than not, I believe it makes sense to use Cartesian
          try  to  figure  out  ways  to  squeeze  more  machines  into   robots to remove parts and then use the other robot types
          their plants. One way to accomplish this is by setting   in downstream and offline applications within the factory.
          up the robot to release the parts at the clamp end of   That being said, do your homework to determine what is
          the molding machine. This allows machines to be placed   best for your requirements.
          closer together. With this setup, it is easy to configure a   Jason Cornell has worked in the plastics injection molding industry
          gantry-style robot to traverse along the machine to drop   for 25 years, specializing in robotics and automation
          the parts at the clamp end. On the other hand, this is
          almost impossible for a six-axis robot.
