FeAtures




          Payload                                                                               controllers, blenders,
          Cartesian and articulated-arm robots can both handle                                  granulators and
          substantial  payloads. The  main  consideration  with  six-                           o per ato r  wo r k
          axis robots is that the payload rating can vary, based                                stations all competing
          on the axis positions, or where the robot is within its                               for space around a
          work envelope. Speed is also impacted by the payload.                                 molding cell, most
          Cartesian robots on the other hand, keep their rated                                  man ufact ure rs
          payload capacity throughout their full range of motions,                              want to minimize
          and they can maintain their maximum payload capacity                                  any additio nal
          at all speeds. Collaborative robots typically have a much                             equipment’s  impact
          lower payload capability than both Cartesian and standard   on the area. A floor-mounted six-axis robot will require
          articulated-arm robots. In molding, payload plays such an   an immense amount of room around the machine, and the
          important factor in choosing robots. Because most molders   press may have to be modified to allow the safety guarding
          never know what job may be coming down the line, it is   to remain open during robot operation. This adds to safety
          important to choose a robot with enough payload capacity   concerns, as well as costs to modify the equipment. The
          not only for today, but for the future as well. I always say   counterpoint to this is a top-entry gantry robot, which
          it is better to have the payload capacity and not need it,   frees  up  valuable  floor  space.  If  a  six-axis  robot  were
          then need it and not have it.                         mounted on top of the machine, it would typically have to
                                                                be oversized to allow the reach required to pick the part
                                            When  considering   and move it all the way outside the machine to deposit it
                                            payload, note that   on a conveyor or pallet.
                                            the part and runner
                                            weights  may  be  a   Makers of collaborative robots promote that they don’t
                                            very small portion   require guarding. This may be true for the robot itself,
                                            of  the  total  load.   but this may not reflect the entire picture. What if the
                                            End-of-arm tooling   robot was entering the injection machine from the back
                                            (EOAT) can have     side of the press (rear gate opened)? What if degating of
                                            docking features,   the parts was required? What if you were running a high-
                                            shuttle  cylinders,   temperature material, and the parts need to be cooled
                                            rotatory units,     prior to an operator handling them? In these scenarios,
                                            multiple  grippers,   even though the robot itself is “collaborative,” other parts
          sensors, quick change mechanisms, etc. The weight of   of the process may not be, so guarding would be required.
          these can add up very quickly. And when you consider   If you considered mounting the cobot on the operator
          high-cavitation molds, even very small-tonnage molding   side of the machine, that indeed might be a layout where
          applications can require extremely high robot payloads.  guarding would be unnecessary. But think about what that
          Flexibility                                           would do to the molding cycle time. The robot would have
                                                                to open the front gate, extract the parts, close the gate
          There is no disputing that six-axis robots provide a wide   and the press would start the next cycle. Although you
          range  of  motion  flexibility. That  being  said,  Cartesian   would  have  more
          robots can be equipped with servo rotational axes at their   consistency than
          wrists. These additional axes can provide up to six axes of   with  an  operator
          total motion on the linear or gantry robot. Although this   performing the
          still doesn’t compare to the total motion flexibility of an   same functions,
          articulated arm, these features can provide linear robots   this   incr eas e
          with much more flexibility than many commonly assume.
                                                                in cycle time
          Floorspace                                            would be very
          The floor space around a molding machine is a scarce and   detrimental to
          valuable commodity. With equipment such as temperature   overall production


                                                                                    35    July  2019   Plastics News
