TECHNOLOGY






          Optimax looks to overcome the challenges of inspecting highly reflective
          moving parts

                                                                                 nario, and proprietary anti-reflection
                                                                                 (AR) techniques need to be applied.
                                                                                 These techniques require the genera-
                                                                                 tion of multiple images using different
                                                                                 directional  lighting  modules. These
                                                                                 images are then fused together to
                                                                                 create a single, reflection-free image.
                                                                                 According to the company, due to
                                                                                 the inherently complex nature of this
                                                                                 process, most existing AR techniques
                                                                                 do not perform robustly enough for
                                                                                 actual  deployment  on a production
                                                                                 floor.
                                                                                 The challenge is compounded when
              uality  assurance  (QA)  is an es-  In numerous  manufacturing  facilities,
          Qsential step of every  manufac-   the parts and modules produced are   the parts are in motion. In many cas-
          turing  process  —  by  ensuring  parts  made of materials that are highly re-  es, highly reflective parts are moving
          are made to specifications, manufac-  flective, such as metals or plastics. Ex-  through the required inspection sta-
          turers can avoid the notorious costs  amples include metallic parts just out   tion and cannot be stopped to enable
          associated with  defective  products.  of the forging or machining process,   stationary inspection.  Until recently,
          However, inspecting highly reflective  coated printed circuit boards (PCBs)   it was considered impossible to fuse
          moving parts has historically been  on electronics manufacturing lines, or   together  multiple images  where  the
          challenging  for traditional machine  metallic  elements assembled in me-  part has a different location and spa-
          vision solutions, meaning  automated  chanical assembly lines.         tial orientation in each image. How-
          QA was not an option, it is claimed   Reflective  objects  create  a  challenge   ever, a solution is now available.
          that the Inspekto S70 overcomes    for visual quality inspection since light   The solution — a technological break-
          these issues.                      reflected  towards  the  camera  often   through
          The process of visual quality inspec-  causes  image  saturation  and loss of   Inspekto has solved this problem by
          tion  can generally  be  divided  into  details. High dynamic range (HDR) is   leveraging several new developments
          three consecutive steps — image ac-  a common methodology used to re-  to create a unique, patent-pending AR
          quisition, which refers to the process  duce reflections in an image. This is a   technology.
          of acquiring  a high-quality  image  of  technique used to reproduce a great-  The first is its Autonomous Machine
          the item to be inspected; part recog-  er dynamic range of luminosity than  Vision  AI (AMV-AI)  technology,  con-
          nition, where the  inspection system  is traditionally possible with standard  taining three AI-based engines work-
          recognises that the acquired image  digital imaging or photographic tech-  ing in tandem. The first of the three
          contains the part to inspect; and final-  niques.                      engines  is the  Acquisition AI engine,
          ly part inspection, which is the analysis   However,  a  significantly  bigger  chal-  a unique AI technology  created  to
          done to establish whether the part is   lenge  is when the  light  source is an   adapt the  parameters  of an electro-
          good or defected. When parts made   embedded  lighting  module,  which  is   optics system to a specific use-case, in
          of highly reflective material are mov-  part of the inspection system, with an   real time. The second engine recog-
          ing, for example on a conveyor belt,   illumination path that is parallel to the   nises the part to be inspected, while
          the  image  acquisition step  becomes   camera’s line of sight (LOS). In these   the  third  determines  whether  it  is
          particularly challenging  for machine   cases, the likelihood of back reflection   good or defected by comparing it to
          vision systems.                    and its intensity increases.        the characteristics  of a perfect part,
          The challenge—reflective and moving  HDR is far from adequate in this sce-  memorised  during  the  initial set  up
                                                                                 process.
