TECHNOLOGY NEWS




          est gen- eration. In an extremely efficient way,      ing of deposits and enables the change of poly-
          this  melt  blender  continuously  exchanges  cen-    mer or color within a very short period of time.
          tral and boundary flows, thus yielding high mix-      However, only if the blender housing is exactly
          ing performance at short in- stalled length. What     tuned to the melt blender and its interfaces an
          is more, the parabol- ic flow profile approaching     opti- mum cleaning behavior can be achieved.
          the extruder outlet is converted effectively into a   It is a known fact that the devil is in the details,
          plug flow. Correspondingly, the melt dis- charged     which is why it is recommended to purchase
          from the melt blender flows at perfectly constant     melt blenders as system solutions including their
          speed and tempera- ture. This is the basic pre-       specially de- signed housings and suitable con-
          requisite for opti- mum process control. Thanks       nection adapters.
          to the pro- cess window considerably enhanced,
          set- ting process parameters is much easier and       Mechanical strength is a critical as- pect of melt
          faster. Even with high extruder out- put rates,       blenders. Under extreme cir- cumstances, e. g.
          layer thickness tolerances, sur- face qualities and   start-up after a short- ened heating phase, in-
          other quality character- istics can be adhered to     correct lay-out or insufficient design of melt
          within the ranges defined. Additionally, distribu-    blenders may even lead to destruction of the
          tion of addi- tives and color pigments within in      mixer structure, as well as of downstream com-
          the melt is far more homogeneous. This can, for       ponents such as feed blocks, dies and cal- ibra-
          example, improve the protective ef- fect of an        tion units. This is why melt blenders must have a
          UV stabilizer added as a master- batch, or may        robust design and must be made of correspond-
          allow for lower dosage. To provide for optimum        ing high-quality ma- terials by suitable produc-
          benefit of the melt blender, it should sit at the     tion methods. While, in industrial practice, one
          end of the pro- cess line, if possible, i.e., right in   always  starts  from the  worst-case  scenario,  it
          front of the die or feed block.                       is recommended to use melt blenders made of
                                                                highly rigid materials and with very thick-walled
          Good Cleaning Behavior and High Strength              structures only, as can be seen in the Title figure.

          When choosing a melt blender, it is cru- cial for     Retrofitting Demands
          the unit to have outstanding self-cleaning prop-
          erties, in addition to good mixing performance.       In particular, when retrofitting an extru- sion
          This is to make sure the flow passes homoge-          line with a melt blender, the space available is
          neously through the entire blender, in or- der to     often limited. Highly efficient mixers with short
          prevent deposits that will increase pressure loss     installed lengths and low pressure loss have the
          and require additional cleaning. The monolithic       edge over larger units here. In most cases, such
          structure of the patented SMB plus melt blend-        types of mixers can be integrated very easily
          er raises the bar in this respect. Extrusion trials   into the existing plant, without having to displace
          have shown that a red colored polypro- pylene         the extruder or cool- ing line. If using pressure
          is 100 % removed by a subsequent colorless PP         drop-opti- mized melt blenders, the extruder is
          after a cleaning time of only 5-6 times the melt      usually able to make up for the addition- al pres-
          blender volume (Fig. 2). Following this in-line       sure drop without problems. If re- quired, an ad-
          cleaning, no traces of red color could be found,      ditional melt pump is very helpful here, but, in
          not even when disassembling the blender. This         fact, is rarely necessary.
          op- timum self-cleaning behavior prevents build-                               Source – Plastics Technology
